Place of Origin:
Hefei，Anhui，China
Brand Name:
Shinny
Certification:
Certification Support, Customizable Services
Model Number:
HZB909YCANX-HL
The HZB909 pointer-type intelligent dashboard is specially designed to meet the durability and intelligence requirements of electric forklifts in complex environments. The core hardware of the product has outstanding adaptability: the DC12V/24V universal power supply enables it to be easily adapted to different vehicle models. The front IP54 protection capability effectively resists the invasion of water vapor and dust on site. The installation method of the steering column is convenient for flexible deployment in various cockpits.
Beyond the limitations of traditional pointer instruments, this forklift dashboard is equipped with a powerful vehicle network function, which can be operated through a mobile phone APP or touch screen to achieve vehicle communication, positioning monitoring and operation data storage. In terms of security, it not only offers convenient login management methods such as card swiping, fingerprint recognition, and facial recognition, but also builds a comprehensive safety protection network for drivers by integrating BSD, DMS, and 360-degree surround view systems. The CE certification passed by some models is a powerful proof of their durable quality and outstanding performance.
|
Operating Voltage |
DC12V |
|
Operating Temperature |
-30°C to 75°C |
|
Protection Level |
IP54 |
|
Connector Model |
DJ7161-2.3-21 16pin |
|
Communication Way |
CAN Communication |
|
Display Language |
Chinese / English |
1. Wide Voltage Compatibility: support DC12V/24V dual system, the working voltage covers DC10-32V, easy to cope with voltage fluctuations.
2. Full Environmental Adaptation: Stable operation under extreme temperatures of -30℃~80℃, reliable in both cold and heat.
3. Multi-dimensional Monitoring: integrated oil/water temperature/timing 3-in-1 display, 14 kinds of LED status indication (including charging, oil pressure, etc.), instant warning of hidden faults.
4. Ultra-low Power Consumption: dynamic operating current ≤ 700mA, standby power consumption of only 2mA, worry-free range.
5. Strong Protection: IP55 dustproof and waterproof, excellent performance in vibration and humidity environment.
Q: What is the function and application of forklift dashboard HZB909YCANX?
A: HZB909 is a pointer-type intelligent forklift dashboard specially designed for harsh working conditions. It features wide-voltage power supply, dust-proof and water-proof characteristics, as well as flexible steering column installation methods. It also integrates vehicle networking, safe login and multiple driving assistance functions, making it a practical solution for enhancing the availability and safety of engineering vehicles.
Q:What quality standards and certifications does our forklift dashboard HZB909YCANX comply with?
A: We can support certifications such as CE and UL for different export regions. Additionally, our products undergo a series of tests including waterproof testing, high-temperature resistance testing, aging testing, and salt spray testing. This ensures a 95% pass rate for quality testing and a 100% pass rate for product delivery.
Q: What range of services does Shinny offer to support clients?
A: Shinny delivers professional customized services, we provide design, sample test, and manufacture tailored products according to client requirements. We also provide integrated system solutions alongside products, offering one-stop services to efficiently advance the intelligent and electrified transformation of industrial development.
Q: How Shinny provide after-sale services of forklift dashboard HZB909YCANX?
A: We have a dedicated team of after-sales engineers and an overseas marketing team, offering 24/7 online support,comprehensive product manuals and repair guides, which promise that we always provide attentive and reliable after-sales service.
Q: What are the standard shipping and logistics processes for delivering orders?
A: We strictly adhere to packaging standards to ensure product safety during transit. Partnering with international couriers such as UPS and FedEx, we guarantee timely delivery.
